Bench Lathe Machine

Bench Lathe Machine

CQ 6230

Category: Tag:
Weight 125 kg
Dimensions 1200 × 560 × 540 cm
Type

CQ 6230-1Phase, CQ 6230-3Phase
Max. Swing Over Bed (mm)

210
Max. Swing Over Carriage (mm)

122
Distance between centers (mm)

520
Bed width (mm)

115
Spindle Bore (mm)

20
Spindle Taper

MT 3
Spindle Speed (rpm)

140 – 1800
Metric threads (mm)

11/0.4 – 3
Inch threads

11/8 – 56 TPI
Tool Post Travel (mm)

60
Max. Cross Travel (mm)

100
Compound Travel (mm)

500
Taper of tailstock (mm)

MT 2
Tailstock Travel (mm)

50
Motor Power (KW)

550
Net Weight (KG)

135
Packing Dimension ( L x W x H ) (mm)

1200 x 560 x 540
